PES60 Hybrid Energy System - 60 kVA - 92 kWh

-- English --
- Field of application: Construction
- Power: 72 kW (98 HP)
- Empty weight: 3000 kg
- Make of engine: Battery System: LIFePO4
- Generator capacity: 72 kVA
- CE mark: yes
- Frequency: 50
- Options: Battery, Control Panel
- Voltage: 400
- Drill equipment: Battery, Control Panel
- Transport dimensions (LxWxH): 1,6x1,1x1,6
Please contact us for more information.

-- Deutsch --
- Verwendungszweck: Bauwesen
- Leistung: 72 kW (98 PS)
- Leergewicht: 3000 kg
- Motormarke: Battery System: LIFePO4
- Generatorleistung: 72 kVA
- CE-Kennzeichnung: ja
- Transportabmessungen (L x B x H): 1,6x1,1x1,6
- Optionen: Battery, Control Panel
Setzen Sie sich fur nahere Auskunfte mit uns in Verbindung.

-- Nederlands --
- Toepassingsgebied: Bouw
- Vermogen: 72 kW (98 PK)
- Ledig gewicht: 3000 kg
- Merk motor: Battery System: LIFePO4
- Generatorvermogen: 72 kVA
- CE markering: ja
- Afmetingen (LxBxH) (m): 1,6x1,1x1,6
- Opties: Batterij, Bedieningspaneel
Portable Hybrid System - Portable Energy Storage System - Solar System - Battery Energy Storage Systems
The PES500 is 60 kVA and 92 kWh.

- Continiuous chargeduration* (AC Charger): Unlimited
- Max. charge power: kW 1x30 - Automatic control according to changes in battery temperature.
- 3 Phase
- Noise level dBA@7m: 50

DC/AC System:
- Rated power: 60 kVA / 60kW
- Output voltage: AC V 380 /400 / 415
- Stanby AC charger power: kW 1x30
- Parallel / On Grid function

PV System:
- Rated power kWp: 60
- Input voltage: DC V 200-800

Battery System:
- LiFePO4 / 92 kWh
- Rated voltage: DC V 614
- Cooling system: Air-cooled

These systems can store energy from various sources, including Solar, Wind, Generator electricity, and the City grid, and discharge it when needed, providing high-quality electric energy.

This model is also possible in PES30 - 36 kVA, 36 kW, 62 kWh

Power connection Input:
- AC socket: 3P/5W, 1x60kW, 1x30kW
- AC copper: 3P/4W, 60kW
- DC socket: 60kW
Power connection Output:
- AC socket: 3P/5W, 1x60kW
- AC socket: 1P, 1x16A; 3P, 1x32A
- AC copper: 3P/4W, 60kW
