QAS5 100 JD S3A Valid inspection, *Guarantee! Die

-- English --
- Type of fuel: Diesel
- Operating hours: 13740
- Field of application: Construction
- Empty weight: 2345 kg
- Make of engine: John Deere
- Generator capacity: 100 kVA
- Serial number: ESF403928
- Transport dimensions (LxWxH): 2.85x1.1x1.62
Please contact us for more information.

-- Deutsch --
- Kraftstofftyp: Diesel
- Betriebsstunden: 13740
- Verwendungszweck: Bauwesen
- Leergewicht: 2345 kg
- Motormarke: John Deere
- Generatorleistung: 100 kVA
- Seriennummer: ESF403928
- Transportabmessungen (L x B x H): 2.85x1.1x1.62
Setzen Sie sich fur nahere Auskunfte mit uns in Verbindung.

-- Nederlands --
- Brandstofsoort: Diesel
- Bedrijfsuren: 13740
- Toepassingsgebied: Bouw
- Ledig gewicht: 2345 kg
- Merk motor: John Deere
- Generatorvermogen: 100 kVA
- Serienummer: ESF403928
- Afmetingen (LxBxH) (m): 2.85x1.1x1.62
Pfeifer Heavy Machinery B.V is an official Atlas Copco dealer.

This Atlas Copco Is Also Available For Rent!

Manufacturer: Atlas Copco
Typ: QAS5 100 JD S3A
Building year: New
Fuel: Diesel

Electrical data
Rated frequency: (1) Hz 50 60
Rated voltage (2) V 400 480
Prime power (PRP) kVA / kW 100 / 80 114 / 91
Rated standby power (ESP) kVA / kW 110 / 88 125 / 100
Power factor cos ? 0,8
Rated current (PRP) A 150 137
Single step load capability (G2) acc. ISO-8528/5 80 85%

Fuel tank capacity / Optional: 250 / 592
Fuel consumption at 100% PRP load 23 26,7 l/h
Fuel autonomy at full load / Optional: 10 / 23,7 8,6 / 20,4 h

Engine
Model: John Deere Turbo
Speed rpm: 1500 1800
Rated net power (with fan) kWm: 88,6 100
Aspiration: Turbocharged and intercooled
Speed control: Mechanical / Electronic
No. Of cylinders: 4
Coolant: Parcool
Swept volume: 4,4 L

Altinator
Model: LEROY SOMER LSA 44.3 S5
Rated Output (ESP 27ºC): kVA 110 131
Degree of protection / Insulation class: IP 23 / H

Noise Level
Sound power level (LwA): dB(A) 91 95
Sound pressure level (LpA) at 7m: dB(A) 63 67

* 60Hz models available, please consult.
* Other voltages available, please consult.

CE (Declaration of Conformity)

More detailed pictures / product movie on our website.

pfeifermachinery.com

Above specifications are subject to change without prior notice and subject to errors.
